Barcode Printers
110mm Thermal Label Printer
TLP-7704
Thermix TLP-7704
110mm direct thermal label printer with USB & LAN connectivity
110mmEasy loadingBarcodeUSBLANFast SpeedWindowsRetail
Enquire About Thermix TLP-7704Key Features
- Direct thermal printing — no ribbon required
- USB and LAN connectivity
- 203 DPI resolution, maximum print speed 160 mm/s
- Supports Android, Windows, and iOS
- Prints 1D barcodes and QR codes
The Thermix TLP-7704 is a compact 110mm thermal label printer designed for shipping labels, inventory tags, and retail barcode labels. Direct thermal printing means no ribbon is required, keeping running costs low and media changes simple.
USB and LAN connectivity keep it flexible across Android, Windows, and iOS workflows. It speaks TSPL/CPCL and ESC/POS commands and prints 1D barcodes and QR codes at up to 160 mm/s and 203 DPI.
Specifications
Technical data from the official Thermix TLP-7704 datasheet.
| Printing Method | Direct Line Thermal |
|---|---|
| Interfaces | USB / LAN |
| Print Command | TSPL / CPCL (ESC/POS) |
| Print Speed | 160 mm/s (max) |
| Resolution | 203 DPI (8 dot/mm) |
| Media Sensors | Dual — transmissive & reflective |
| Paper Types | Continuous, label, folded, tag |
| Paper Width | 30–110 mm (max 832 points) |
| Effective Width | 104 mm |
| Paper Thickness | 0.06–0.30 mm |
| 1D Codes | UPC, EAN, CODE39, and common 1D symbologies |
| 2D Codes | QR Code, PDF417 |
| Drivers | Win XP–11, macOS; iOS / Android support |
| Charging | External DC 24V / 2.5A |
| Print Head Life | 100,000,000 pulse/dot or 50 km |
| Dimensions | 180 × 78 × 75 mm |
| Weight | 0.8 kg (with accessories) |
| Operating Temp | 0°C – 45°C |
| Accessories | USB cable, power adapter, manual |
